Magnetism 9: Electric Motors Using a magnetic field to exert torque on a rotating circuit.
⇐ Use this menu to view and help create subtitles for this video in many different languages.
You'll probably want to hide YouTube's captions if using these subtitles.
- Let's say we have a magnetic field that's coming out of the
- right side of the screen.
- And it's not just along the screen, it's actually three
- dimensional.
- So it's going above the screen, below, but the
- direction of the magnetic field is from the
- right to the left.
- Let me just draw that.
- And I'm not going to draw a bunch of the field vector
- arrows because that'll just take up a lot of valuable
- space on our-- so that's the vector magnetic field.
- It's down here, too.
- If I could, I would draw it above your screen and below
- your screen.
- But it's coming from the right to the left.
- And then in that magnetic field I
- have an electric circuit.
- I won't draw the whole circuit right now.
- I'll do that in a second.
- But let's say I have-- part of the electric
- circuit is a loop.
- And the loop looks like this.
- I'm trying to draw it carefully.
- So that we can-- because I think a careful drawing will
- be more useful in a second than an
- uncarefully drawn drawing.
- So let's see.
- So it's a loop.
- You can almost-- you could imagine taking a paper clip
- and putting it into this shape.
- Oh, that's good enough, I think.
- And I have a current going in this direction
- in this paper clip.
- So this is the positive, that's the negative.
- So the current is going like that.
- Current is going in a loop like that.
- The current's coming out of this end, it's
- coming into this end.
- And let's say that loop of-- it could be a paper clip or
- anything-- let's say that it can rotate.
- And that's important.
- What's going to happen?
- Well, my magnetic field is coming in this direction.
- The current is going down here, up here.
- What's going to be the net force of the magnetic
- field on this loop?
- Well, let's try it out.
- And it turns out it's going to be a different magnitude at
- different points of the current.
- So here.
- And we don't worry about-- all we're worried about right now
- is direction.
- And then maybe a little intuition of the magnitude.
- So we know that the force of the magnetic field is equal to
- the current times the length vector cross
- the magnetic field.
- Well, what would be the force of the magnetic field on this
- segment of wire?
- We could call this L.
- And that L goes in the same direction as the current.
- Well, let's see.
- Current is just a scalar, but L is going down.
- Magnetic field going to the left.
- Cross product.
- Cross product, I take my right hand, put my index finger in
- the direction of the current, or in the direction of L,
- because that's the first term of the cross product.
- So that's the index finger.
- So my index finger goes down, because that's the direction
- of the current.
- And then my middle finger-- and remember, you have to do
- this with the right hand.
- If you do it with the left hand, you're going to get the
- opposite result.
- And now my middle finger is going to go in the direction
- of the field.
- So let me point my middle finger.
- My middle finger is going to go in the
- direction of the field.
- I keep having to look at my own hand.
- And then my other two fingers are just going to do what they
- need to do.
- So that's my third finger.
- That's my pinky.
- And then what is my thumb going to do?
- What is my thumb going to do?
- Well, my hand-- that's my hand.
- This is what my hand is doing.
- I'm pointing downward.
- And my palm is kind of pointing at my body.
- So what is my thumb doing?
- I know it's hard to see.
- This is my middle finger right here.
- So my thumb is on the other side of this drawing.
- And my thumb is pointing downwards.
- I hope you see that.
- And you try it with your own hand.
- So my thumb is pointing downwards.
- So the direction of the force created by the magnetic field
- on this current is going to go downward.
- So let me draw that.
- So the force vector-- I'll do it in this
- orangey brown color.
- The force vector on this segment of the wire is going
- to be going down.
- Now what about this segment of the wire?
- Well, think about it.
- This segment of the wire, the L vector-- this L vector--
- It's parallel to the magnetic field just in
- the opposite direction.
- And so when you take the cross product-- remember, the cross
- product is you're multiplying the magnitude of the vectors
- that are perpendicular to each other.
- But if this is the L vector right here, there's no
- component of it that it's perpendicular to
- the magnetic field.
- So the magnetic field and the current are in the same plane.
- They're parallel.
- They're not orthogonal at all.
- There's no components of them that are at 90 degrees.
- So when you take the cross product, you're going to see
- that the net force on this segment of the wire is 0.
- And likewise on this segment of the wire and this segment
- of the wire.
- Because they aren't in any way perpendicular.
- No components of them are even perpendicular.
- So fair enough.
- So all we know right now is the magnetic field is exerting
- a downward force on this side of our paper
- clip or of our circuit.
- Now what about this side?
- Well, same thing.
- Take the cross product.
- If this is our L, L cross B.
- So take your index finger in the direction--.
- So index finger goes like that.
- Your middle finger will go in the direction of the field.
- So your middle finger is going to look something like that.
- And then your other two fingers are
- going to be like that.
- And what is your thumb going to do?
- And this has to be your right hand to work.
- Your thumb is going to point straight up.
- This is like the heel of your thumb.
- Your thumb is going to--.
- I don't know if that's a good drawing of a thumb.
- But your thumb is essentially pointing out of the page.
- Middle finger in the direction of the current, or in the
- direction of our length.
- Sorry, index finger in the direction of the current.
- Middle finger in the direction of the field.
- Thumb points out of the page.
- Do that with your own right hand and you'll see that the
- net force of the magnetic field on this segment of the
- wire is going to be upwards.
- Let me do it in a different color just to get some
- contrast.
- So what's going to happen?
- Assuming that this circuit can rotate,
- what's going to happen?
- On this side there's a downward force.
- On this side there's an upward force.
- So the magnetic field is actually exerting a
- torque on this wire.
- If you viewed this little dotted line as our axis of
- rotation, the whole coil is actually going to rotate
- around that line.
- And so there's some force over here, along this whole line
- being applied downwards.
- And it's actually perpendicular
- to our moment arm.
- If you remember what we had learned about torque.
- So it will actually exert all of that force-- that force
- times this distance will be the torque
- applied on this side.
- And then likewise there's a torque-- it's really the same
- sign, in the same direction, because here on the other side
- of the arm it's pushing upwards.
- So they're not going to cancel out.
- They're both going to reinforce.
- And this whole coil is going to be
- turning in this direction.
- Here it's going to be moving up out of your video screen.
- Here it's going to be moving down into your video screen.
- Now what happens?
- I'm going to try to not run out of time either.
- So it's going to start rotating.
- So the left hand side's going to go below the page.
- The right hand side's going to be above the page.
- I want to draw some perspective, that's why I'm
- just drawing it bigger.
- Maybe it looks like that.
- Maybe my circuit starts to look like that.
- And I'll redraw my axis of rotation.
- So this is my axis of rotation.
- And on the way I drew it-- this part, the axis of
- rotation is still in the plane of our video.
- But this part of the coil is, you could
- imagine it popping out.
- I wish you had 3D glasses on.
- It's popping out of your screen.
- This part is going into your screen.
- And the current is still going in the same direction.
- Current is going in that direction there.
- So using the same right hand rule, on this side of the wire
- the magnetic field is going to be exerting a
- net downward force.
- But the torque is actually going to be less because our
- moment arm distance is going to be like-- I want to draw it
- with some perspective.
- It's going to look something like that.
- So it's going to be going to the left and behind the page
- while the torque is still just into the page.
- So you would actually take the component of the torque that's
- perpendicular.
- So there's some component of the torque that's actually
- perpendicular.
- I don't want to confuse you too much.
- But you could imagine the torque lessens.
- Even though the net magnetic force is the same, the
- component of that force that's perpendicular to your moment
- arm, that lessens.
- So there's still going to be some torque that's going to be
- causing it to rotate downwards in that direction.
- Sorry.
- You know what?
- I drew this wrong here.
- We're pushing up on the right hand side, we're pushing down
- on the left hand side.
- So the direction is going to be like that.
- Pushing up on the right hand, down on the left hand.
- So you're still going to be doing the same thing here.
- You are going to be pushing up here.
- But you're going to be pushing up directly out of the page.
- But that's not completely perpendicular
- to the moment arm.
- So the component that is perpendicular, that's actually
- creating rotational torque, that's going
- to be a little less.
- And then you could imagine that all the way to the point,
- the coil's going to keep rotating with smaller torque.
- At some point you'll be looking at it head on.
- So I can just draw it like a straight line, right?
- You can imagine.
- This arm is on top and this arm is behind it.
- And at this point, what's going to happen?
- All the magnetic force on this top arm is going
- to be popping up.
- It's going to be popping up out of your page but it's not
- going to be providing any torque.
- Because it's not perpendicular anymore to your moment arm.
- And likewise, on the bottom behind this, if you could
- visualize this, it would be exerting a net downward force.
- And that's also not going to be helpful.
- But maybe they have some angular momentum so the wire
- will still rotate.
- But then when it still rotates,
- what's going to happen?
- And this is where I'll leave you with a
- little bit of a conundrum.
- Actually, I don't want to go over the Youtube limit, so I'm
- going to continue this in the next video and I'll show you
- the conundrum.
- See you soon.
Be specific, and indicate a time in the video:
At 5:31, how is the moon large enough to block the sun? Isn't the sun way larger?
|
Have something that's not a question about this content? |
This discussion area is not meant for answering homework questions.
Discuss the site
For general discussions about Khan Academy, visit our Reddit discussion page.
Flag inappropriate posts
Here are posts to avoid making. If you do encounter them, flag them for attention from our Guardians.
abuse
- disrespectful or offensive
- an advertisement
not helpful
- low quality
- not about the video topic
- soliciting votes or seeking badges
- a homework question
- a duplicate answer
- repeatedly making the same post
wrong category
- a tip or feedback in Questions
- a question in Tips & Feedback
- an answer that should be its own question
about the site
Share a tip
Suggest a fix
Have something that's not a tip or feedback about this content?
This discussion area is not meant for answering homework questions.
