- Let's say I have the vector field v.
- The vector at any given point is equal to minus-- or the
- magnitude of my x direction is actually dependent on y.
- So where we are in the y coordinate and the xy plane.
- Plus-- and then my magnitude in the y direction
- is dependent on x.
- Fair enough.
- So first, let's just chuck through this, and
- figure out it's curl.
- So the curl of v.
- It is equal to our del vector operator, cross v.
- Which is nothing but this.
- And even though this looks like a two dimensional vector field,
- we actually have to take the cross product in 3 dimensions.
- Because a curl is just like torque, and when you-- like we
- did the right hand rule when we studied-- well, I hope you
- watched some of the videos on magnetism and torque-- but the
- torque actually goes in a direction that is perpendicular
- to both of the vectors in your cross product.
- If both of these only have x and y components, your actual
- result is going to be in the z direction.
- It's going to be perpendicular to both of these vectors.
- So when you take the cross product, you still have to
- do it in 3 dimensions.
- So i j k, partial with respect to x, partial with respect to
- y, partial with respect to z.
- The x component is minus y.
- The j component is x.
- And we have no k component.
- This one should be a little bit cleaner to calculate
- than the last example.
- So this is going to be equal to-- well, see the i
- component-- let's cross out its column and its row.
- So it's going to be the partial with respect to y of 0
- minus the partial with respect to z of x.
- Minus that.
- And all of that times i minus-- and now it's going
- to be the j component.
- Remember, you do plus minus plus.
- So minus and this is the j component.
- Cross out its row and column, the partial derivative
- of x with respect to 0.
- Or partial derivative of 0 with respect to x, actually.
- Minus the partial derivative of z.
- Or the partial derivative of the [? vector ?]
- z of minus y.
- That's its j component.
- And finally, plus its k component.
- Row and column.
- So the partial derivative with respect to x minus the partial
- derivative of y with respect to minus y.
- And I know you can't read it, but that's that minus y there,
- and that's the k component.
- And now let's simplify it.
- I'll simplify it above it.
- So this term-- let's see, partial derivative of 0.
- Well, that's 0.
- Partial derivative of x with respect to z.
- Well, as far as z's concerned, x is a constant, so that's 0.
- Partial derivative of 0 with respect to x, 0.
- Partial derivative of minus y with respect to z.
- As far as z's concerned, y is also constant.
- So that's 0.
- So all we're left is with this last term.
- That was pretty straightforward.
- Why don't we just cross all of that out?
- And that makes intuitive sense, too, right?
- Because at least from x's point of view, the rotation is--
- although, the rotation, if you think about it, is going to be
- in the direction perpendicular to both the x direction and
- perpendicular to the direction in which it is changing.
- You could kind of view it orthogonally, to its direction
- of motion, which is y.
- So it would be the z direction.
- If that confuses you, don't worry about it.
- But if it doesn't, then you could apply the same
- argument to the j vector.
- But anyway, lets simplify this.
- So this is equal to the partial derivative of
- x with respect to x.
- Well, that's just 1.
- Minus the partial derivative of y-- of minus y
- with respect to y.
- Well, that's just minus 1.
- So it equals 2.
- So the curl, at any point of this vector field, is 2.
- Let's see what this vector field looks like, and let's
- see if that gives us-- if our intuition holds
- in this example.
- And let me try to make it a little bit bigger.
- Make the window bigger.
- There you go.
- Well, I think it's clear, you know, right when you look at
- it, that this vector field looks like it's spinning.
- If you were to stick something, especially in the middle, it's
- very clear that it would spin.
- But what might be a little unintuitive-- you might think,
- wow, well, wouldn't something spin faster near the center
- than it would here?
- Why is the-- you know, the curl we got is 2.
- It's a constant.
- The curl is the same throughout this entire vector field.
- So you'll be like, whoa, that's kind of implying that the field
- is making something spin equally, no matter where
- you are in the field.
- Let's see if that makes sense.
- Well, in the middle, it definitely makes sense that
- something is spinning.
- If I had a little stick here, I'd be pushing in this
- direction, with not that much of a magnitude in
- that direction.
- And then I'd be pushing down to the right in this direction,
- so it would cause it to spin.
- But what if I had that same stick here?
- You'd say, well, on the top right I'm pushing
- up, up and to the left.
- And the bottom left, I'm also pushing up and to the left.
- You know, it wouldn't spin as much.
- But it would.
- Because the difference in magnitudes of these 2-- you
- could almost view them as the torque producing forces-- the
- difference in magnitude is enough that you'd still have
- the same counterclockwise rotation here as you
- would have here.
- So because the curl is a constant positive number, when
- we look at the xy plane like this, if you put a twig-- that
- same twig anywhere where you put it on this plane--
- it'll have the same counterclockwise rotation.
- I think that's pretty neat.
- Now let's do a little experiment.
- What would have happened if this was plus y.
- So let's just do that experiment.
- If this was plus y then this would have been plus y, then
- this final term-- we would have taken the partial derivative
- with respect to y of plus y-- and so this would have
- been 1 minus plus 1.
- And then our curl would have been 0.
- Which would have meant that we would have had no rotation.
- And what's the intuition of that?
- Well, if we just look at it mathematically, if we have 0
- curl, somehow, the rotation in our x direction must be being
- offset by a rotation in the y direction.
- That the torques must be just perfectly
- offsetting each other.
- Let's see what happens if I were to change.
- So this was our old graph.
- Let me actually change it to my new vector field.
- So that's our new vector field.
- This is our vector field plus yi plus xj.
- And now the curl is 0 everywhere.
- Which implies, or which means, that I could put a twig
- anywhere here and I'm not going to get any kind of rotation.
- Let's see if that makes sense.
- If I put a twig in the center, or some kind of stick in
- the center, let's see.
- I would have the forces or the fluids pushing in in this
- direction, but they're not helping to rotate, and pushing
- out in that direction.
- Well, that's not going to help me either.
- So I'm definitely not going to rotate there.
- And actually, you could put a twig anywhere.
- And maybe a twig might be pushed in a direction.
- For example, if I put a twig here, it's going to be pushed
- outward by the flow of the water, by the velocity
- of the water.
- But it's not going to rotate.
- So the [? ink ?]
- kind of holds.
- That's even though I kind of have curl in the x direction,
- or I have curl in the y direction, they're
- offsetting each other.
- So that in 2 dimensions, I actually end up
- having no rotation.
- And actually, this is called an irrotational-- I think that's
- the word-- vector field.
- Where you're not going to have any rotation here.
- All of the-- if you think of it as force or velocity of the
- vector field-- is going to be applying translation to
- objects in that field.
- And actually, just for fun, let's think about the
- divergence of that field.
- Just to, I don't know.
- Just because I have 2 minutes.
- So if I were to think about the divergence of that field, it's
- fairly easy to calculate.
- Let me erase this real fast.
- It's always fun to just interpret a vector
- field to death.
- Let's do the divergence of this one.
- So the divergence of that vector field, is just a
- partial derivative of this with respect to x.
- So div of v is the same thing as our del operator dot
- our vector field, v.
- And that's the partial derivative of this
- with respect to x.
- Well, the partial derivative of y with respect to x is just 0.
- Plus the partial derivative of x with respect to y.
- So this is 0.
- So the divergence of this field is 0.
- And even in the other case, when this was a minus, it
- still would have been 0.
- And does that make sense?
- Well, if we take a circle anywhere here-- let's take it
- in the center, because the center's the most interesting.
- Let's take a circle.
- So we do have some fluid or particles coming in at a
- certain velocity from the bottom right and the top left.
- But just as much is coming out through the top right
- and the bottom left.
- Whatever's coming in through here and here is leaving
- through there and there.
- So if I had an infinitesimally small circle, or sphere, in
- this vector field, I would have no net density increasing.
- Or nothing would be entering into that circle, or in any
- given amount of time the concentration of that
- circle wouldn't change.
- And that's true pretty much anywhere.
- If I were to draw a circle here, because the divergence
- is 0, it's telling us that whatever's coming in in 1
- direction is coming out in the other directions.
- So I'm not getting any denser, or any less dense.
- I have no divergence or convergence.
- So that's just interesting.
- Well, now I've run of time.
- So we're done analyzing this vector field.
- See you in the next video.
